Acura MDX II facelift (2010-2013) 1 2 3 gnd mic in - mic in + Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 gnd mic in - mic in +, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 gnd mic in - mic in + (1 of 1)
1 2 3 GND MIC IN - MIC IN +
ACURALINK CONTROL UNIT (XM RECEIVER) (RIGHT SIDE OF CARGO AREA)
AUDIO REMOTE SWITCH
AUDIO- NAVIGATION UNIT
B-CAN
BACK BUTTON
BLK WIRE
BLU WIRE
BLUETOOTH TRANSCEIVER
BOX (BEHIND LEFT KICK PANEL)
BRN WIRE
CABLE REEL (BEHIND STEERING COLUMN COVER)
COMPUTER DATA LINES SYSTEM
FUSE 32
FUSE 5
FUSE 7
GRN WIRE
GRY WIRE
HANDSFREELINK CONTROL UNIT (UNDER REAR OF CENTER CONSOLE)
HFL BACK BUTTON
HFL NAVIGATION MICROPHONE (FRONT CENTER
HFL TALK BUTTON
HFL-VOICE CONTROL SWITCH
HFT COMM 2 HFT COMM 1 HFT COMM 3 HFT COMM 4 HFT COMM SH
HFT MUTE PPL
HOT AT ALL TIMES
HOT IN ACC OR ON
LT BLU WIRE
LT GRN WIRE
MIDDLE OF DASH)
NAVIGATION DISPLAY UNIT
OF ROOF)
PNK 4 5 6 7 WIRE
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
SOUND SYSTEM
STEERING WHEEL)
TALK BUTTON
UNDER-DASH FUSE/RELAY
USA CANADA
WHT WIRE
Go to component -> Hands free module circuit, except base -> 1 2 3 GND MIC IN - MIC IN +
