Rear wiper/washer circuit for Acura MDX II (2006-2010)

Rear wiper/washer circuit

Get access

B-CAN B-CAN COMBINATION SWITCH CONTROL UNIT BLK WIRE BLU WIRE CONTROL BLOCK FRONT WASHER MOTOR RELAY FUSE 21 FUSE 31 FUSE 7 HOT AT ALL TIMES HOT IN ON OR START LT GRN WIRE MICU NCA WIRE OFF RR WIP RR WASH ORG/ WIRE PARK REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA) MICU VBU REAR WASHER MOTOR RELAY REAR WINDOW WIPER MOTOR (CENTER OF TAILGATE) REAR WINDOW WIPER/ WASHER SWITCH RED WIRE RR WASH RR WIP OFF RR WASH RR WASH RUN WIRE UNDER-DASH FUSE/RELAY BOX (BEHIND VBU WHT WIRE WINDSHIELD WASHER MOTOR (BEHIND RIGHT SIDE OF FRONT BUMPER, ON WASHER RESERVOIR) WIPER/ WASHER SWITCH YEL WIRE
