Headlamp washer circuit, canada for Acura MDX II (2006-2010)
Headlamp washer circuit, canada
B-CAN IGN
BLK WIRE
BLU WIRE
CONTROL BLOCK
FUSE MICU BOX (BEHIND IGN B-CAN LEFT KICK PANEL)
GRN WIRE
HEADLIGHT WASHER MOTOR
HEADLIGHT WASHER RELAY
HEADLIGHT WASHER SWITCH
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY FUSE BOX (RIGHT SIDE OF ENGINE COMPT)
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
RED WIRE
UNDER-DASH FUSE/RELAY
YEL WIRE
