Rear seat entertainment circuit for Acura MDX II (2006-2010)

Rear seat entertainment circuit (1 of 2)

MDX Acura II (2006-2010): Rear seat entertainment circuit (1 of 2)

Get access

AUXILIARY JACK ASSEMBLY BLK WIRE BLU WIRE DIGITAL AUDIO LED CONNECTOR FUSE 8 FUSE 9 GRN WIRE GRY WIRE HOT AT ALL TIMES INTERIOR LIGHTS SYSTEM 1 2 LT BLU WIRE LT GRN WIRE MAIN UNDER-HOOD FUSE BOX (LEFT FRONT OF ENGINE COMPT) NAVIGATION DISPLAY UNIT NTSC NTSC SHLD AUDIO OUT L AUDIO OUT R HP R OUT HP L OUT PNK 18 19 WIRE PNK NTSC GND AUDIO OUT GND AUDIO OUT SHLD HP GND HP SHLD WIRE PNK WIRE PPL PPL PNK WIRE REAR CONTROLLER, SCREEN RED WIRE RR BUS SHLD RR BUS (-) PPL RR BUS- UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) WHT WIRE YEL WIRE

Rear seat entertainment circuit (2 of 2)

MDX Acura II (2006-2010): Rear seat entertainment circuit (2 of 2)

Get access

AUDIO REMOTE SWITCH AUDIO UNIT AUX VIDEO IN AUX VIDEO SHLD AUX VIDEO GND BACK SWITCH BLK WIRE BLU WIRE BRN WIRE CABLE REEL (BEHIND STEERING COLUMN COVER) CHANNEL DOWN SWITCH CHANNEL UP SWITCH FUSE 32 FUSE 5 GRN WIRE GRY WIRE HFL-VOICE CONTROL SWITCH HOT AT ALL TIMES HOT IN ACC OR ON LT BLU WIRE LT GRN WIRE MODE SWITCH NAVIGATION UNIT (ON FLOOR, ORG/ WIRE PNK 18 19 WIRE PNK WIRE PPL PPL PNK WIRE PPL PPL PNK WIRE RED WIRE STEERING WHEEL) TALK SWITCH UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) VOLUME DOWN SWITCH VOLUME UP SWITCH WHT WIRE YEL WIRE
