Front seat heater circuit for Acura MDX II (2006-2010)
Front seat heater circuit
BLK WIRE
BRN WIRE
DRIVER'S SEAT BACK HEATER (UNDER DRIVER'S SEAT)
DRIVER'S SEAT CUSHION HEATER (UNDER DRIVER'S SEAT)
DRIVER'S SEAT HEATER SWITCH
FRONT PASSEN- GER'S SEAT HEATER SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER (UNDER FRONT PASSENGER'S SEAT)
FRONT SEAT HEATER RELAY
FUSE 30
FUSE 4
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HI LO
HOT AT ALL TIMES
HOT IN ON
INDICATORS ON
LIGHT
LO HI
LO HI HI LO
LT BLU WIRE
LT GRN WIRE
ON INDICATORS
RED WIRE
SWITCH
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT/BLU WIRE
YEL WIRE
