Exterior lamps circuit for Acura MDX II (2006-2010)

4 3 9 OFF B-CAN B-CAN BACKUP BLK WIRE BLU WIRE BRAKE LIGHT RELAY (UNDER LEFT SIDE OF DASH) BRAKE PEDAL POSITION SWITCH (TOP OF BRAKE PEDAL ARM) BRN WIRE COMBINATION LIGHT SWITCH COMBINATION SWITCH CONTROL UNIT CONTROL BLOCK CRUISE (BEHIND CONTROL RIGHT KICK SYSTEM PANEL) FUSE 10 FUSE 11 FUSE 20 FUSE 21 FUSE 7 GRN WIRE GRY WIRE H/L H/L BACKUP HAZARD HAZARD WARNING SWITCH HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES HOT IN ON OR START INTERIOR LIGHTS SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM J/C LEFT BRAKE LIGHT/ TAILLIGHT LEFT LICENSE PLATE LIGHT LEFT REAR SIDE MARKER LIGHT LEFT REAR TURN SIGNAL LIGHT LT BLU WIRE LT GRN WIRE MAIN UNDER-HOOD FUSE BOX (LEFT FRONT OF ENGINE COMPT) MICU TO TURN SIGNAL/ HAZARD RELAY (DIAGRAM OFF ORG/ WIRE PARK HEAD HEADLIGHT SWITCH PNK WIRE REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA) RED WIRE RIGHT LICENSE PLATE LIGHT TRAILER LIGHTING RELAY (UNDER REAR FUSE/RELAY BOX) TURN SIGNAL SWITCH UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT) VBU VSA MODULATOR CONTROL UNIT (LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE WIPER/WASHER SWITCH YEL WIRE

+B HAZARD BLK WIRE BLU WIRE BRN WIRE CONTROL BLOCK FROM MICU (DIAGRAM 1 OF 2) FUSE GAUGE CONTROL MODULE GND TURN SW R R TURN LT GRY WIRE HIGH MOUNT BRAKE LIGHT (NOISE CONDENSER) (LEFT SIDE OF CARGO AREA) HOT AT ALL TIMES J/C L TURN LT LEFT FRONT PARKING LIGHT LEFT FRONT SIDE MARKER LIGHT LEFT FRONT TURN SIGNAL LIGHT LEFT POWER MIRROR LEFT SIDE TURN SIGNAL LIGHT LEFT TURN LT LEFT TURN SIGNAL IND LH TURN SW LT BLU WIRE MICU MICU REAR FUSE/RELAY BOX (LEFT SIDE OF CARGO AREA) ORG/ WIRE PNK WIRE PPL RED WIRE RH TURN SW RIGHT BRAKE LIGHT/ TAILLIGHT RIGHT FRONT PARKING LIGHT RIGHT FRONT SIDE MARKER LIGHT RIGHT FRONT TURN SIGNAL LIGHT RIGHT POWER MIRROR RIGHT REAR SIDE MARKER LIGHT RIGHT REAR TURN SIGNAL LIGHT RIGHT SIDE TURN SIGNAL LIGHT RIGHT TURN LT RIGHT TURN SIGNAL IND TAILLIGHT RELAY TRAILER LIGHTING CONTROL UNIT (UNDER REAR FUSE/RELAY BOX) TURN SIGNAL/ HAZARD RELAY TURN SW L UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
