Acura MDX II (2006-2010) vbu b-can fuel sw Wiring diagram
This page shows the only wiring diagram for the component.vbu b-can fuel sw, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vbu b-can fuel sw (1 of 1)
B-CAN
BLK WIRE
BRN WIRE
DRIVER'S MPCS UNIT (IN DRIVER'S DOOR)
FUEL FILL DOOR OPENER SOLENOID (LEFT SIDE OF CARGO AREA)
FUEL FILL DOOR OPENER SWITCH
FUEL FILL DOOR OPENER/ POWER TAILGATE SWITCH
FUEL LID
FUSE 7
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
MICU
PNK WIRE
REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
USA: ENTERTAINMENT PACKAGE CANADA: SPORT
USA: EXCEPT ENTERTAINMENT PACKAGE CANADA: BASE, TECH
VBU
VBU B-CAN FUEL SW
WHT WIRE
