Acura MDX II (2006-2010) sw input cruise ctrl check input can-l can-h Wiring diagram

ATF TEMPERATURE SENSOR (ON TRANSAXLE END COVER) ATP-D ATP-N ATP-R LSA SW INPUT SW INPUT SW INPUT SENS GND SENS GND ATP-FWD ATP-RVS ATP-P BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE PEDAL POSITION SWITCH (TOP OF BRAKE PEDAL ARM) BRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DOWN ENGINE CONTROLS SYSTEM FUSE 10 FUSE 18 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES MAIN UNDER-HOOD FUSE BOX (LEFT FRONT OF ENGINE COMPT) FUSE 11 HOT IN ON OR START INPUT SHAFT (MAINSHAFT) SPEED SENSOR LSC LSB REF VOLT SENS INPUT SENS GND SENS INPUT SENS INPUT LT BLU WIRE LT GRN WIRE MAP SENSOR (TOP OF THROTTLE BODY) MICU OFF ORG/ WIRE OUTPUT SHAFT (COUNTERSHAFT) SPEED SENSOR PARK IN SWITCH PCM (RIGHT FRONT OF ENGINE COMPT) PGM- PNK WIRE PPL REAR FUSE/ RELAY BOX RED WIRE RED/BLK WIRE RED/WHT WIRE SENS GND REF VOLT SHD SHC SHB SHA SEQUENTIAL SPORTSHIFT A/T SHIFT SWITCH SEQUENTIAL SPORTSHIFT MODE SWITCH SHIFT CONTROL SOLENOID VALVE C SHIFT CONTROL SOLENOID VALVE D SHIFT SHIFT CONTROL CONTROL SOLENOID SOLENOID VALVE B VALVE A STARTING/ CHARGING SYSTEM SW INPUT CRUISE CTRL CHECK INPUT CAN-L CAN-H UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) VBSOL WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
