Acura MDX II (2006-2010) svcc plsa plsb wiring diagram
This page shows the only wiring diagram for the component.svcc plsa plsb, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
svcc plsa plsb wiring diagram (1 of 1)
AUTO OPEN
BLK WIRE
CLOSE
COMPUTER DATA LINES SYSTEM
FUSE 3
FUSE 6
GRN WIRE
GRY WIRE
HALL SENSOR
HOT AT ALL TIMES
INPUT CIRCUIT
LT BLU WIRE
LT GRN WIRE
MICU
MOONROOF CLOSE RELAY
MOONROOF MOTOR
MOONROOF OPEN RELAY
ORG/ WIRE
PNK WIRE
PPL
RCV
RED WIRE
SVCC PLSA PLSB
TILT
UNDER-DASH FUSE/RELAY BOX
VMP
WHT WIRE
Go to component -> Power top/sunroof circuit -> SVCC PLSA PLSB
