Acura MDX II (2006-2010) rhdn fhdn fhup refw slfw Wiring diagram
This page shows the only wiring diagram for the component.rhdn fhdn fhup refw slfw, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rhdn fhdn fhup refw slfw (1 of 1)
ATP-P
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S POWER SEAT CONTROL UNIT (UNDER DRIVER'S SEAT)
DRIVER'S POWER SEAT FRONT UP-DOWN MOTOR (UNDER DRIVER'S SEAT)
DRIVER'S POWER SEAT REAR UP-DOWN MOTOR (UNDER DRIVER'S SEAT)
DRIVER'S POWER SEAT SLIDE MOTOR (UNDER DRIVER'S SEAT)
FHM + SLM +
FRONT UP-DOWN SWITCH UP DN
GRN WIRE
GRY WIRE
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK DPMS BUS B-CAN WIRE
PNK RHUP WIRE
PNK WIRE
POWER TILT/ TELESCOPIC STEERING CONTROL UNIT (UNDER LEFT SIDE OF DASH)
PPL
PPL FHM(-) SLM(-)
PPL SEG
REAR UP-DOWN SWITCH FD
RECLINE SWITCH BK FD
RED WIRE
REM(+) RHM(-) REM(-) PNK WIRE
RERW
RHDN FHDN FHUP REFW SLFW
RHM +
SCOM
SG RESE SLSE FHSE RHSE
SLIDE SWITCH BK FD
SLRW
SVCC
VBU PWR
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Driver"s memory seat circuit (1 of 2) -> RHDN FHDN FHUP REFW SLFW
