Acura MDX II (2006-2010) reverse diode (left side of cargo Wiring diagram
This page shows the only wiring diagram for the component.reverse diode (left side of cargo, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram reverse diode (left side of cargo (1 of 1)
ATP-R
ATPR
AUTOMATIC DIMMING INSIDE MIRROR
BACK LT-
BLK WIRE
BRN WIRE
FUSE 21
HOT IN ON OR START
LEFT BACKUP LIGHT
MICU
NAVIGATION UNIT
PCM (RIGHT FRONT OF ENGINE COMPT)
PPL
PPL 1 PPL AREA)
PPL 2
REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA)
REVERSE DIODE (LEFT SIDE OF CARGO
RIGHT BACKUP LIGHT
TRAILER BACKUP RELAY (ACCESSORY INSTALLED) (UNDER REAR FUSE/RELAY BOX)
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT MICU KICK PANEL)
WHT WIRE
Go to component -> Backup lamps circuit -> REVERSE DIODE (LEFT SIDE OF CARGO
