Acura MDX II (2006-2010) off rr wip rr wash Wiring diagram
This page shows the only wiring diagram for the component.off rr wip rr wash, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off rr wip rr wash (1 of 1)
B-CAN
B-CAN COMBINATION SWITCH CONTROL UNIT
BLK WIRE
BLU WIRE
CONTROL BLOCK
FRONT WASHER MOTOR RELAY
FUSE 21
FUSE 31
FUSE 7
HOT AT ALL TIMES
HOT IN ON OR START
LT GRN WIRE
MICU
NCA WIRE
OFF RR WIP RR WASH
ORG/ WIRE
PARK
REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA) MICU VBU
REAR WASHER MOTOR RELAY
REAR WINDOW WIPER MOTOR (CENTER OF TAILGATE)
REAR WINDOW WIPER/ WASHER SWITCH
RED WIRE
RR WASH
RR WIP OFF RR WASH RR WASH
RUN WIRE
UNDER-DASH FUSE/RELAY BOX (BEHIND
VBU
WHT WIRE
WINDSHIELD WASHER MOTOR (BEHIND RIGHT SIDE OF FRONT BUMPER, ON WASHER RESERVOIR)
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Rear wiper/washer circuit -> OFF RR WIP RR WASH
