Acura MDX II (2006-2010) lh turn sw Wiring diagram
This page shows the only wiring diagram for the component.lh turn sw, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh turn sw (1 of 1)
+B HAZARD
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL BLOCK
FROM MICU (DIAGRAM 1 OF 2)
FUSE
GAUGE CONTROL MODULE
GND TURN SW R R TURN LT
GRY WIRE
HIGH MOUNT BRAKE LIGHT (NOISE CONDENSER) (LEFT SIDE OF CARGO AREA)
HOT AT ALL TIMES
J/C
L TURN LT
LEFT FRONT PARKING LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT POWER MIRROR
LEFT SIDE TURN SIGNAL LIGHT
LEFT TURN LT
LEFT TURN SIGNAL IND
LH TURN SW
LT BLU WIRE
MICU
MICU REAR FUSE/RELAY BOX (LEFT SIDE OF CARGO AREA)
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RH TURN SW
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT FRONT PARKING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT POWER MIRROR
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT SIDE TURN SIGNAL LIGHT
RIGHT TURN LT
RIGHT TURN SIGNAL IND
TAILLIGHT RELAY
TRAILER LIGHTING CONTROL UNIT (UNDER REAR FUSE/RELAY BOX)
TURN SIGNAL/ HAZARD RELAY
TURN SW L
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
Go to component -> Exterior lamps circuit (2 of 2) -> LH TURN SW
