Acura MDX II (2006-2010) left high mount brake light brake noise light/ taillight condenser Wiring diagram
This page shows the only wiring diagram for the component.left high mount brake light brake noise light/ taillight condenser, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left high mount brake light brake noise light/ taillight condenser (1 of 1)
A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE A
A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE B
A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE C
ACCESSORY POWER SOCKET RELAY
BLK WIRE
BRN WIRE
BRN/YEL WIRE
CMP SENSOR
DRIVING POSITION MEMORY SWITCH
EGR VALVE, EGR VALVE POSITION IGNITION SENSOR COIL 1
FRONT A/F
GRN/WHT WIRE
HIGH MOUNT BRAKE LIGHT
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
IGNITION IGNITION COIL 2 COIL 3
IGNITION KEY SWITCH/ KEY LIGHT
LEFT BACKUP LIGHT
LEFT HIGH MOUNT BRAKE LIGHT BRAKE NOISE LIGHT/ TAILLIGHT CONDENSER
LEFT LEFT SIDE POWER TURN MIRROR SIGNAL DRIVER'S DEFOGGER LIGHT MPCS UNIT
LEFT LICENSE PLATE LIGHT
LEFT POWER MIRROR
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
MICU
MICU SERVICE CHECK CONNECTOR SOCKET
PCM
PNK WIRE
POWER TAILGATE MOTOR SHIELD
REAR
REAR A/F
REAR WINDOW REAR DEFOGGER WINDOW NOISE DEFOGGER CONDENSER
RIGHT BACKUP LIGHT
RIGHT LICENSE PLATE LIGHT
ROCKER KNOCK ARM OIL SENSOR PRESSURE SHIELD SWITCH
ROOF CONSOLE
SECONDARY
SHIELD CKP SENSORS (A, B)
TRANSMISSION RANGE SWITCH
TURN SIGNAL/ HAZARD RELAY
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
USA: ENTERTAINMENT PACKAGE, SPORT, CANADA: ELITE PACKAGE
WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (3 of 3) -> LEFT HIGH MOUNT BRAKE LIGHT BRAKE NOISE LIGHT/ TAILLIGHT CONDENSER
