Acura MDX II (2006-2010) keyless buzzer Wiring diagrams
This page contains all the electrical diagrams for the component. keyless buzzer, in which he is found in the car Acura MDX II (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram keyless buzzer (1 of 2)
B-CAN
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DRIVER'S DOOR KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/KEY CYLINDER SWITCH (IN DRIVER'S DOOR)
DRIVER'S DOOR LOCK KNOB SWITCH
DRIVER'S DOOR LOCK SWITCH
DRIVER'S DOOR SWITCH (IN LEFT "B" PILLAR)
DRIVER'S MPCS UNIT (IN DRIVER'S DOOR)
FRONT PASSENGER'S DOOR LOCK SWITCH
FRONT PASSENGER'S DOOR SWITCH (IN RIGHT "B" PILLAR)
FRONT PASSENGER'S MPCS UNIT (IN FRONT PASSENGER'S DOOR)
FULL LATCH SWITCH
GRN WIRE
GRY WIRE
IGNITION KEY SWITCH
IGNITION KEY SWITCH/ KEY LIGHT
ILL (+) LOCK UNLOCK PNK WIRE
J/C
KEYLESS BUZZER
KEYLESS BUZZER/ POWER TAILGATE BUZZER (BEHIND REAR BUMPER)
LOCK
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PNK/ LOCK WIRE
POWER TAILGATE CLOSER UNIT (CENTER OF TAILGATE)
PPL
PPL UNLOCK UNLOCK SGND
REAR FUSE/ MICU RELAY BOX (LEFT SIDE OF CARGO AREA)
RED WIRE
SCOM OHSW
TAILGATE OUTER HANDLE SWITCH
UART B-CAN
UART VBU
UNDER-DASH FUSE/RELAY BOX
UNLOCK
UNLOCK KEY UNLOCK KEY LOCK LOCK UNLOCK VBU SGND ILL (+) LOCK UNLOCK
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (2 of 2) -> KEYLESS BUZZER
