Acura MDX II (2006-2010) handsfree link control Wiring diagram
This page shows the only wiring diagram for the component.handsfree link control, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram handsfree link control (1 of 1)
AM/FM ANTENNA LEAD CONNECTOR 1 2 3
AUDIO UNIT
AUXILIARY JACK ASSEMBLY (EXCEPT ENTERTAINMENT PACKAGE)
BLK WIRE
BLU WIRE
COM 1
COM 2
COM 3
COM 4
COM SHLD
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM AIR CONDITIONING SYSTEM
DET
FUSE 32
GRN WIRE
GRY (OR BRN) WIRE
GRY WIRE
HANDSFREE LINK CONTROL
HOT IN ACC OR RUN
L CH-
LT BLU WIRE
LT GRN WIRE
NAVIGATION SYSTEM
OUT
OUT SHLD
PNK WIRE
PPL
PPL PPL
R CH-
RED WIRE
SHLD
SIG GND
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNIT (UNDER REAR OF CENTER CONSOLE)
WHT WIRE
Go to component -> Premium radio circuit, usa (1 of 4) -> HANDSFREE LINK CONTROL
