Acura MDX II (2006-2010) front passenger's door lock knob switch Wiring diagrams
This page contains all the electrical diagrams for the component. front passenger's door lock knob switch, in which he is found in the car Acura MDX II (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front passenger's door lock knob switch (1 of 2)
"C" PILLAR)
+B +B DOOR LK
2 1 PNK WIRE
B-CAN
B-CAN IG KEY SW
B-CAN VBU
BLK WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL BLOCK
D/L MTR (DR)
D/L MTR (LK)
D/L MTR (UNL)
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH (IN FRONT PASSENGER'S DOOR)
FRONT PASSENGER'S DOOR LOCK KNOB SWITCH
FUSE 3
FUSE 7
FUSE 8
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOOD SWITCH (CENTER FRONT OF ENGINE COMPT)
HORNS SYSTEM
HOT AT ALL TIMES
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH (IN LEFT REAR DOOR)
LEFT REAR DOOR SWITCH (IN LEFT
LT GRN WIRE
MICU
NOT USED NOT USED
PNK PNK WIRE
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
POWER TOPS SYSTEM
PPL
REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA)
RED WIRE
RIGHT REAR DOOR
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH (IN RIGHT REAR DOOR)
SECURITY IND
SWITCH (IN RIGHT "C" PILLAR)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
VBU
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (1 of 2) -> FRONT PASSENGER'S DOOR LOCK KNOB SWITCH
