Acura MDX II (2006-2010) elec brake Wiring diagram
This page shows the only wiring diagram for the component.elec brake, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram elec brake (1 of 1)
BACKUP LAMPS CIRCUIT
BATT +
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
BRN/WHT WIRE
CRUISE CONTROL SYSTEM
ELEC BRAKE
ELECTRIC BRAKE SWITCH
EXTERIOR LAMPS CIRCUIT
FUSE 1
FUSE 11
FUSE 13
FUSE 2
FUSE 3
FUSE 30
FUSE 4
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
HOT W/ PARKING LIGHTS ON
KICK PANEL)
LT BLU WIRE
LT GRN WIRE
MAIN UNDER-HOOD FUSE BOX (LEFT FRONT OF ENGINE COMPT)
MICU
PPL
R TURN L TURN
REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA)
RED WIRE
RED/GRN WIRE
STOP SW
TRAILER BACKUP RELAY (UNDER REAR FUSE/RELAY BOX)
TRAILER CHARGE RELAY (UNDER REAR FUSE/RELAY BOX)
TRAILER CONNECTOR (4-PIN)
TRAILER CONNECTOR (7-PIN)
TRAILER ELECTRIC BRAKE CONNECTOR (UNDER LEFT SIDE OF DASH)
TRAILER LIGHTING CONTROL UNIT (UNDER REAR FUSE/RELAY BOX)
TRAILER LIGHTING RELAY (UNDER REAR FUSE/RELAY BOX)
UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Trailer tow circuit, accessory -> ELEC BRAKE
