Acura MDX II (2006-2010) driver's door key cylinder switch 1) un lock 2) lock Wiring diagram
This page shows the only wiring diagram for the component.driver's door key cylinder switch 1) un lock 2) lock, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's door key cylinder switch 1) un lock 2) lock (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DOWN OFF UP OFF
DRIVER'S DOOR KEY CYLINDER SWITCH 1) UN LOCK 2) LOCK
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/KEY CYLINDER SWITCH (IN DRIVER'S DOOR)
DRIVER'S DOOR LOCK KNOB SWITCH 1) UN LOCK 2) LOCK
DRIVER'S MPCS UNIT (IN DRIVER'S DOOR)
DRIVER'S POWER WINDOW MOTOR (IN DRIVER'S DOOR)
FUSE
FUSE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
JUNCTION CONNECTOR
LEFT REAR POWER WINDOW SWITCH
LT BLU WIRE
LT GRN WIRE
MAIN UNDER- HOOD FUSE BOX
MICU B-CAN
MULTI FUSE 3
ORG/ WIRE
P/W MAIN FUSE
PASSENGER'S MPCS UNIT (IN FRONT PASSENGER'S DOOR)
PNK WIRE
POWER WINDOW RELAY
PPL
PULSER
RED WIRE
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
VBU
WHT WIRE
YEL WIRE
Go to component -> Power windows circuit (1 of 2) -> DRIVER'S DOOR KEY CYLINDER SWITCH 1) UN LOCK 2) LOCK
