Acura MDX II (2006-2010) cmp ckp sensors sensor Wiring diagram
This page shows the only wiring diagram for the component.cmp ckp sensors sensor, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cmp ckp sensors sensor (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
CMP CKP SENSORS SENSOR
CONTROL BLOCK
DRL SENSOR
ELD
ETCS CONTROL SUB RELAY RELAY
FOG LIGHT INTERIOR LIGHTS RELAY RELAY
FROM FUSE 7 (DIAGRAM 1 OF 6)
FROM MULTI-FUSE 1 (DIAGRAM 1 OF 6)
FRONT BLOWER MOTOR RELAY
FUEL PUMP SHORT PIN
FUSE 1
FUSE 10 FUSE 11
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 2
FUSE 22
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
HEADLIGHT LOW BEAM RELAY
HEADLIGHT WASHER RELAY (CANADA)
HORN RELAY
IGNITION COIL RELAY
INJECTOR INJECTOR INJECTOR
LEFT DRL
LT GRN WIRE
MAIN RELAY 1
MAIN RELAY 2
MULTI FUSE 3
ORG/ WIRE
PCM
PNK WIRE
R/B FUSE
RADIATOR FAN RELAY
RADIATOR FAN RELAY DIODE SHORT PIN
RED WIRE
RIGHT DRL
TAILLIGHT HEADLIGHT RELAY HIGH BEAM RELAY
TO P/W MAIN (DIAGRAM 3 OF 6)
TRAILER ELECTRIC BRAKE CONNECTOR (ACCESSORY INSTALLED)
UNDER-DASH FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> CMP CKP SENSORS SENSOR
