Acura MDX II (2006-2010) check in vsp in Wiring diagram
This page shows the only wiring diagram for the component.check in vsp in, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram check in vsp in (1 of 1)
ACTIVE DAMPER SYSTEM CONTROL UNIT (LEFT SIDE OF CARGO AREA)
BLK WIRE
BLU WIRE
BRN WIRE
CHECK IN VSP IN
COMBINATION LIGHT SWITCH
COMBINATION SWITCH CONTROL UNIT
DLC (UNDER MIDDLE OF DASH)
FUSE
FUSE (RIGHT SIDE OF ENGINE COMPT)
GRN WIRE
HEAD
HEADLIGHT ADJUSTER CONTROL UNIT (UNDER RIGHT SIDE OF DASH)
HEADLIGHT SWITCH
HOT IN ON OR START
HOT W/ HIGH BEAM HEADLIGHT RELAY ENERGIZED
J/C
LEFT FRONT STROKE/ HEADLIGHT LEVELING SENSOR (ON LEFT FRONT SUSPENSION)
LEFT HEADLIGHT LEVELING MOTOR
LEFT REAR STROKE/ HEADLIGHT LEVELING SENSOR (ON LEFT SIDE OF REAR SUBFRAME)
LT BLU WIRE
LT GRN WIRE
MOTOR
OFF
PARK
PCM (RIGHT FRONT OF ENGINE COMPT)
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
UNDER-DASH FUSE/RELAY BOX (BEHIND
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Headlamps leveling circuit, sport -> CHECK IN VSP IN
