Acura MDX II (2006-2010) b-can scom ohsw wiring diagram
This page shows the only wiring diagram for the component.b-can scom ohsw, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
b-can scom ohsw wiring diagram (1 of 1)
B-CAN
B-CAN OF CARGO AREA)
B-CAN SCOM OHSW
BLK WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH (IN LEFT "B" PILLAR)
DRIVER'S MPCS UNIT (IN DRIVER'S DOOR)
FRONT PASSENGER'S DOOR SWITCH (IN RIGHT "B" PILLAR)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
IG KEY SW
IGNITION KEY LIGHT
IGNITION KEY SWITCH
IGNITION KEY SWITCH/ KEY LIGHT
IMMOBILIZER KEYLESS CONTROL UNIT
LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR)
LT GRN WIRE
MICU INTR LT (-)
NCA WIRE
ORG/ WIRE
PACKAGE, SPORT, CANADA: ELITE PACKAGE) (LEFT SIDE OF CARGO AREA)
PASSENGER'S MPCS UNIT (IN FRONT PASSENGER'S DOOR)
PNK WIRE
POWER TAILGATE CONTROL UNIT (USA: TECHNOLOGY/ ENTERTAINMENT
REAR FUSE/RELAY BOX (LEFT SIDE MICU
RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR)
TAILGATE OUTSIDE HANDLE SWITCH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UART VBU B-CAN
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
VBU B-CAN
VBU UART
WHT WIRE
YEL WIRE
Go to component -> Entry light timer circuit -> B-CAN SCOM OHSW
