Acura MDX II (2006-2010) acura accessory Wiring diagram
This page shows the only wiring diagram for the component.acura accessory, which is found in the car Acura MDX II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram acura accessory (1 of 1)
ACURA ACCESSORY
ACURALINK ACURALINK CONTROL UNIT REPROGRAMMING (XM RECEIVER) CONNECTOR
BASE, TECHNOLOGY PACKAGE; USA: SPORT PACKAGE
BLK WIRE
BRN WIRE
CIGARETTE LIGHTER
DRIVER'S POWER SEAT CONTROL UNIT
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT HEATER SWITCH
EXCEPT BASE
FACTORY
FRONT ACCESSORY POWER SOCKET
FRONT BLOWER POWER TRANSISTOR
FRONT FRONT PASSENGER'S PASSENGER'S SEAT BELT SEAT BUCKLE CUSHION SWITCH HEATER
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S MPCS UNIT
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT HEATER SWITCH
GLOVE BOX LIGHT
GRN/YEL WIRE
HANDSFREELINK CONTROL UNIT
KEYLESS/ POWER TAILGATE BUZZER
NAVIGATION INTERFACE DISPLAY UNIT DIAL
PNK WIRE
POWER TILT/ TELESCOPIC STEERING CONTROL UNIT
REAR CLIMATE CLIMATE CONTROL CONTROL PANEL UNIT
REAR DIFFERENTIAL TAILGATE REAR OUTER WINDOW HANDLE WIPER MOTOR SWITCH
REAR FUSE/RELAY BOX MICU (LEFT SIDE OF CARGO AREA)
RIGHT POWER MIRROR
RIGHT POWER MIRROR POSITION SENSOR
RIGHT POWER MIRROR RIGHT POWER MIRROR DEFOGGER
RIGHT REAR RIGHT REAR DOOR LOCK POWER ACTUATOR/ WINDOW KNOB SWITCH SWITCH
RIGHT REAR RIGHT SIDE BRAKE LIGHT/ MARKER TAILLIGHT LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT SECOND ROW SEAT ODS HEATER UNIT
RIGHT SIDE TURN SIGNAL LIGHT
SH-AWD CONTROL UNIT
SH-AWD RELAY
STEERING ANGLE SENSOR
TAILGATE LATCH SWITCH
USA: BASE, CANADA
USA: EXCEPT BASE
YAW RATE, LATERAL, LONGITUDINAL ACCELERATION SENSOR
Go to component -> Ground distribution circuit (2 of 3) -> ACURA ACCESSORY
