Shift interlock circuit for Acura MDX I (2000-2006)
Shift interlock circuit
A/T SHIFT SWITCH (BEHIND CENTER CONSOLE
BLK WIRE
BRAKE PEDAL POSITION SWITCH (AT TOP OF BRAKE PEDAL ARM)
DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
FUSE 47
FUSE 8
FUSE 9
GAUGE ASSEMBLY
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IGNITION KEY SWITCH/ KEY LIGHT
KEY INTERLOCK SOLENOID
KEY INTERLOCK SWITCH
PANEL)
PARK PIN SWITCH
POWERTRAIN CONTROL MDULE (PCM) (ON RIGHT SIDE OF ENGINE COMPT)
RED/BLK WIRE
SHIFT LOCK DIODE (UNDER RIGHT SIDE OF DASH)
SHIFT LOCK RELAY (UNDER LEFT SIDE OF DASH)
SHIFT LOCK SOLENOID (UNDER CENTER CONSOLE, AT BASE OF SHIFT LEVER ASSEMBLY)
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-HOOD FUSE/RELAY BOX (AT RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
