Radio circuit, withbose for Acura MDX I (2000-2006)

ACCESSORY POWER SOCKET RELAY ANTENNA ANTENNA SUBLEAD AUDIO UNIT BASS + -RR +RR BLK WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) FUSE 8 FL + CTRL SW B+ FL- FR - RL- RR + RR - FL - FR + RL + FR (-) FUSE 9 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN ACC OR ON LT BLU WIRE LT GRN WIRE NAVIGATION DISPLAY UNIT NAVIGATION UNIT (IF EQUIPPED) (UNDER RIGHT FRONT SEAT) NCA WIRE ORG/ WIRE PASSENGER'S MULTIPLEX CONTROL UNIT PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PPL RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE RL + MUTE RR - RL - FR - FL - DIM CTRL - GROUND RL + RR + BASS- BATT POWER GROUND RL - RR - SECURITY INPUT SHIELD FR + FL - STEREO AMPLIFIER (UNDER MIDDLE OF DASH) UNDER-HOOD FUSE SUB-FUSE BOX FUSE 4 UNDER-HOOD FUSE/RELAY BOX (AT RIGHT SIDE OF ENGINE COMPT) FUSE 48 W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE

ANTENNA AMPLIFIER ANTENNA SUBLEAD BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/YEL WIRE BRN/BLK WIRE BRN/WHT WIRE CABLE REEL DRIVER'S DOOR SPEAKER DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/WHT WIRE JUNCTION CONNECTOR LEFT POWER MIRROR LEFT REAR DOOR SPEAKER LEFT TWEETER LT GRN WIRE MAST ANTENNA MODE SWITCH NAVIGATION SYSTEM NCA WIRE RADIO REMOTE/VOICE CONTROL SWITCH REAR TWEETER REAR WOOFER RED WIRE RED/GRN WIRE RED/YEL WIRE REMOTE CASE GROUND CONNECTOR (IN STEERING WHEEL) RIGHT POWER MIRROR RIGHT REAR DOOR SPEAKER RIGHT TWEETER SEEK UP SWITCH STEERING WHEEL) VOLUME DOWN SWITCH VOLUME UP SWITCH WHT/BLU WIRE YEL WIRE YEL/WHT WIRE
