Power top/sunroof circuit for Acura MDX I (2000-2006)
Power top/sunroof circuit
BLK WIRE
BLU WIRE
CLOSE
CLOSE OR TILT OPEN
FUSE 1
FUSE 15
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
MOONROOF CLOSE RELAY
MOONROOF LIMIT SWITCH (MIDDLE OF ROOF)
MOONROOF MOTOR (MIDDLE OF ROOF)
MOONROOF OPEN RELAY (BEHIND LEFT SIDE OF DASH)
MOONROOF SWITCH
MOONROOF SWITCH LIGHTS
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
POWER WINDOW RELAY
POWER WINDOWS SYSTEM
RED WIRE
RED/BLK WIRE
TILT
YEL WIRE
YEL/RED WIRE
