Passenger power seat circuit for Acura MDX I (2000-2006)
Passenger power seat circuit
BACKWARD
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
DOWN
FORWARD/
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER SEAT FRONT UP-DOWN MOTOR (UNDER FRONT PASSENGER'S SEAT)
FRONT PASSENGER'S POWER SEAT REAR UP-DOWN MOTOR (UNDER FRONT PASSENGER'S SEAT)
FRONT PASSENGER'S POWER SEAT RECLINE MOTOR (UNDER FRONT PASSENGER'S SEAT)
FRONT PASSENGER'S POWER SEAT SLIDE MOTOR (UNDER FRONT PASSENGER'S SEAT)
FUSE 3
FUSE 5
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
RED WIRE
RED/YEL WIRE
YEL WIRE
YEL/GRN WIRE
