Passive restraints circuit for Acura MDX I (2000-2006)
Passive restraints circuit
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
DRIVER'S SEAT BELT SWITCH (UNDER DRIVER'S SEAT)
DRIVER'S SEAT BELT TENSION REDUCER SOLENOID
DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
FRONT PASSENGER'S SEAT BELT SWITCH (UNDER FRONT PASSENGER'S SEAT)
FRONT PASSENGER'S SEAT BELT TENSION REDUCER SOLENOID (RIGHT "B" PILLAR)
FUSE 9
HOT IN ON OR START
LT GRN WIRE
ORG/ WIRE
RED/BLU WIRE
SUPPLEMENTAL RESTRAINTS SYSTEM
YEL WIRE
