Backup lamps circuit for Acura MDX I (2000-2006)
Backup lamps circuit
BACK- UP LIGHT
BLK WIRE
DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
FUSE 9
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
HOT IN ON OR START
LEFT TAILLIGHT ASSEMBLY
MEMORY SYSTEMS
PCM (ON RIGHT SIDE OF ENGINE COMPT)
RED WIRE
REVERSE RELAY
RIGHT TAILLIGHT ASSEMBLY
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
WHT WIRE
