Acura MDX I (2000-2006) Computer data lines circuit

BLK WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE CAN HIGH CAN LOW DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH, BEHIND LOWER COVER) DIAG N DIAG P DRIVER'S MULTIPLEX CONTROL UNIT DRIVER'S POWER SEAT CONTROL UNIT (W/ MEMORY) (UNDER DRIVER'S SEAT) DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) EXCEPT NAVIGATION GRN/RED WIRE GRY WIRE HOT AT ALL TIMES IMMOBILIZER CONTROL UNIT -RECEIVER (IN STEERING COLUMN COVER) JUNCTION CONNECTOR LT BLU WIRE LT GRN/BLK WIRE MES CONNECTOR (UNDER LEFT SIDE OF DASH) MULTIPLEX CONTROL INSPECTION CONNECTOR (UNDER LEFT SIDE OF DASH) NAVIGATION NAVIGATION SERVICE CHECK CONNECTOR (UNDER FRONT PASSENGER'S SEAT) NAVIGATION UNIT (UNDER RIGHT FRONT SEAT) OF ENGINE COMPT) PASSENGER'S MULTIPLEX CONTROL UNIT PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (ON RIGHT SIDE RED WIRE RED/WHT WIRE SRS UNIT (BEHIND LOWER CENTER OF DASH) TPMS RECEIVER UNIT (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (AT RIGHT SIDE OF ENGINE COMPT) FUSE 46 VSA MODULATOR CONTROL UNIT (ON LEFT SIDE OF ENGINE COMPT) VTM-4 CONTROL UNIT (AT RIGHT SIDE OF CARGO AREA, BEHIND REAR SIDE TRIM PANEL) WHT WIRE WHT/GRN WIRE
