Acura MDX I (2000-2006) washer on off Wiring diagram
This page shows the only wiring diagram for the component.washer on off, which is found in the car Acura MDX I (2000-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram washer on off (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU/WHT WIRE
DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
FUSE 11
GRN WIRE
GRN/YEL WIRE
HOT IN ON OR START
LT GRN WIRE
LT GRN/BLK WIRE
PARK
PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
REAR WINDOW WIPER INTERMITTENT CONTROL UNIT (LEFT SIDE OF CARGO AREA)
REAR WINDOW WIPER MOTOR (BEHIND TAILGATE TRIM PANEL)
REAR WINDOW WIPER/WASHER SWITCH
RUN WIRE
WASHER
WASHER ON OFF
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Rear wiper/washer circuit -> WASHER ON OFF
