Acura MDX I (2000-2006) under-hood fuse/relay box eld unit Wiring diagram
This page shows the only wiring diagram for the component.under-hood fuse/relay box eld unit, which is found in the car Acura MDX I (2000-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram under-hood fuse/relay box eld unit (1 of 1)
A/C PRESSURE SWITCH
BATTERY
BLK WIRE
BLK/WHT WIRE
BRAIDED WIRE
BRN/BLK WIRE
BRN/YEL WIRE
CKP SENSORS (A, B)
CMP SENSOR
DATA LINK CONNECTOR
DIMMER RELAY
EGR VALVE/ EGR VALVE POSITION SENSOR
ENGINE
FAN CONTROL RELAY
FRONT BLOWER MOTOR RELAY
FRONT, REAR A/F SENSOR SHIELD
FRONT, REAR SECONDARY
GRY WIRE
IGNITION COIL 1, IGNITION COIL 2,
IGNITION COIL 3
IGNITION COIL 5 IGNITION COIL 4
IGNITION COIL 6
IMMOBILIZER CONTROL UNIT- RECEIVER
INTERMITTENT WIPER RELAY
J/C
KNOCK SENSOR SHIELD
LOW BEAM RIGHT HEADLIGHT
PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
POWERTRAIN CONTROL MODULE
RADIATOR FAN MOTOR
REAR WINDOW WASHER MOTOR
RIGHT FOG LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL/ PARKING LIGHT
SECURITY HOOD SWITCH
SHIELD
THROTTLE ACTUATOR CONTROL MODULE
TRANSMISSION
TRANSMISSION RANGE SWITCH
UNDER-HOOD FUSE/RELAY BOX ELD UNIT
VTEC OIL PRESSURE SWITCH
WINDSHIELD WASHER MOTOR
Go to component -> Ground distribution circuit (1 of 4) -> UNDER-HOOD FUSE/RELAY BOX ELD UNIT
