Acura MDX I (2000-2006) under-hood fuse sub-fuse box (left side of Wiring diagram
This page shows the only wiring diagram for the component.under-hood fuse sub-fuse box (left side of, which is found in the car Acura MDX I (2000-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram under-hood fuse sub-fuse box (left side of (1 of 1)
A/C CONDENSER FAN MOTOR (ON RADIATOR SUPPORT)
A/C CONDENSER FAN RELAY
A/C DIODE A (BEHIND RIGHT SIDE OF DASH)
A/C DIODE B
A/C PRESSURE SWITCH (RIGHT REAR OF ENGINE
AF SENSOR RELAY (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
CLIMATE CONTROL UNIT (LOWER CENTER OF DASH, FORWARD OF CENTER CONSOLE)
COMPT)
DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
ECT SENSOR (AT REAR OF ENGINE, ON TOP OF WATER PASSAGE)
ENGINE COMPT)
ENGINE CONTROLS SYSTEM
FAN CONTROL RELAY (IN MULTI- RELAY BOX)
FUSE 3
FUSE 57
FUSE 58
FUSE 9
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON
JUNCTION
LT BLU WIRE
ORG/ WIRE
PASSENGER'S UNDERDASH FUSE/RELAY BOX
POWERTRAIN CONTROL MODULE (ON RIGHT SIDE OF ENGINE COMPARTMENT)
RADIATOR FAN MOTOR (FRONT OF ENGINE COMPT)
RADIATOR FAN RELAY
RED/ORG WIRE
RED/WHT WIRE
UNDER-HOOD FUSE SUB-FUSE BOX (LEFT SIDE OF
UNDER-HOOD FUSE/RELAY BOX (AT RIGHT SIDE OF ENGINE COMPARTMENT)
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Cooling fan circuit -> UNDER-HOOD FUSE SUB-FUSE BOX (LEFT SIDE OF
