Acura MDX I (2000-2006) scom slfw at-p pos 1 input ign vsu Wiring diagram

BLK WIRE BLK/BLU WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE BWD COMM LINE BATT INPUT GROUND GROUND DOOR LOCKS SYSTEM DOOR MULTIPLEX CONTROL UNIT (IN DRIVER'S DOOR) DRIVER'S LUMBAR SUPPORT SWITCH DRIVER'S POSITION MEMORY SWITCH DRIVER'S POWER SEAT CONTROL UNIT (UNDER DRIVER'S SEAT) DRIVER'S POWER SEAT FRONT UP-DOWN POSITION SENSOR DRIVER'S POWER SEAT RECLINE MOTOR (UNDER DRIVER'S SEAT) DRIVER'S POWER SEAT RECLINE POSITION SENSOR DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) DRIVING POSITION MEMORY SWITCH LIGHT FHSE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND RHM - REM - MEMO BUTTON POS 1 PNK WIRE POS 2 REBW FHDN RHDN MEMORY IN RHSE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE REF REFW FHUP RHUP BUS RESE RHM + REM + SCOM SLFW AT-P POS 1 INPUT IGN VSU SENSOR SLBW AT-R DRSWD POS 2 INPUT GROUND SLM + IND 1 CTRL BATTERY FHM - SLM - IND 2 CTRL GROUND FHM + SLSE GND SLSE VSS IN WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
