Acura MDX I (2000-2006) map lights Wiring diagrams
This page contains all the electrical diagrams for the component. map lights, in which he is found in the car Acura MDX I (2000-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram map lights (1 of 2)
AUTO
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
DOOR
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR SWITCH (AT LEFT "B" PILLAR)
DRIVER'S FOOTWELL LIGHT
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
DRIVER'S VANITY MIRROR LIGHT
FRONT INDIVIDUAL MAP LIGHTS
FRONT PASSENGER'S DOOR COURTESY LIGHT
FRONT PASSENGER'S DOOR SWITCH (AT RIGHT "B" PILLAR)
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S VANITY MIRROR LIGHT
FUSE 11
GAUGE ASSEMBLY
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
ILLUMI- NATION
IN-LINE DIODE 1
IN-LINE DIODE 2
IN-LINE DIODE 4 IN-LINE DIODE 3
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHTS SWITCH
LEFT
LEFT REAR DOOR COURTESY LIGHT
LEFT REAR DOOR SWITCH
LT GRN/BLK WIRE
MAP LIGHTS
MEMORY SYSTEMS
OFF
OFF ON ON
ORG/ WIRE
PASSENGER'S MULTIPLEX CONTROL UNIT
PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
REAR CEILING LIGHT
REAR INDIVIDUAL MAP LIGHTS
RED WIRE
RED/BLK WIRE
RIGHT
RIGHT REAR DOOR COURTESY LIGHT
RIGHT REAR DOOR SWITCH
ROOF CONSOLE
TAILGATE LATCH SWITCH (BEHIND TAILGATE TRIM PANEL)
TAILGATE LIGHTS
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Courtesy lamps circuit -> MAP LIGHTS
Wiring diagram map lights (2 of 2)
AUTO
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BRN WIRE
COURTESY LAMPS CIRCUIT
DOOR MULTIPLEX CONTROL UNIT
DRIVER'S DOOR LOCK KNOB SWITCH
DRIVER'S DOOR SWITCH (AT LEFT "B" PILLAR)
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
FRONT INDIVIDUAL MAP LIGHTS
FRONT PASSENGER'S DOOR SWITCH (AT RIGHT "B" PILLAR)
FUSE 11
FUSE 47
FUSE 9
GAUGE ASSEMBLY
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION KEY LIGHT
IGNITION KEY SWITCH
IGNITION KEY SWITCH/ KEY LIGHT
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHT SWITCH
LEFT REAR DOOR SWITCH
LT GRN/BLK WIRE
MAIN CIRCUIT
MAP LIGHTS
MEMORY SYSTEMS
OFF ON
PASSENGER'S MULTIPLEX CONTROL UNIT
PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT REAR DOOR SWITCH
ROOF CONSOLE
TAILLIGHT RELAY (BEHIND LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (AT RIGHT SIDE OF ENGINE COMPT)
WHT/BLK WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Entry light timer circuit -> MAP LIGHTS
