Acura MDX I (2000-2006) high mount brake lights Wiring diagram
This page shows the only wiring diagram for the component.high mount brake lights, which is found in the car Acura MDX I (2000-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high mount brake lights (1 of 1)
AUXILIARY JACK ASSEMBLY (W/ REAR ENTERTAINMENT SYSTEM)
BLK WIRE
BRAKE LIGHT FAILURE SENSOR
BRN WIRE
BRN/BLK WIRE
GRY WIRE
HIGH MOUNT BRAKE LIGHTS
J/C
LEFT REAR DOOR LOCK KNOB SWITCH
LEFT TAILLIGHT ASSEMBLY
LICENSE PLATE LIGHTS
NAVIGATION UNIT
REAR ACCESSORY POWER SOCKET
REAR ACCESSORY POWER SOCKET RELAY
REAR STEREO AMPLIFIER (EXCEPT BOSE)
REAR VIEW CAMERA CONTROL UNIT
REAR WINDOW DEFOGGER
REAR WINDOW WIPER INTERMITTENT CONTROL UNIT
REAR WINDOW WIPER MOTOR
RIGHT REAR DOOR LOCK KNOB SWITCH
RIGHT TAILLIGHT ASSEMBLY
TAILGATE LATCH SWITCH
TRAILER LIGHTING CONNECTOR
VTM-4 CONTROL UNIT
Go to component -> Ground distribution circuit (4 of 4) -> HIGH MOUNT BRAKE LIGHTS
