Acura MDX I (2000-2006) front passenger's vanity mirror light Wiring diagrams
This page contains all the electrical diagrams for the component. front passenger's vanity mirror light, in which he is found in the car Acura MDX I (2000-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front passenger's vanity mirror light (1 of 2)
AUTO
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
DOOR
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR SWITCH (AT LEFT "B" PILLAR)
DRIVER'S FOOTWELL LIGHT
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
DRIVER'S VANITY MIRROR LIGHT
FRONT INDIVIDUAL MAP LIGHTS
FRONT PASSENGER'S DOOR COURTESY LIGHT
FRONT PASSENGER'S DOOR SWITCH (AT RIGHT "B" PILLAR)
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S VANITY MIRROR LIGHT
FUSE 11
GAUGE ASSEMBLY
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
ILLUMI- NATION
IN-LINE DIODE 1
IN-LINE DIODE 2
IN-LINE DIODE 4 IN-LINE DIODE 3
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHTS SWITCH
LEFT
LEFT REAR DOOR COURTESY LIGHT
LEFT REAR DOOR SWITCH
LT GRN/BLK WIRE
MAP LIGHTS
MEMORY SYSTEMS
OFF
OFF ON ON
ORG/ WIRE
PASSENGER'S MULTIPLEX CONTROL UNIT
PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
REAR CEILING LIGHT
REAR INDIVIDUAL MAP LIGHTS
RED WIRE
RED/BLK WIRE
RIGHT
RIGHT REAR DOOR COURTESY LIGHT
RIGHT REAR DOOR SWITCH
ROOF CONSOLE
TAILGATE LATCH SWITCH (BEHIND TAILGATE TRIM PANEL)
TAILGATE LIGHTS
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Courtesy lamps circuit -> FRONT PASSENGER'S VANITY MIRROR LIGHT
Wiring diagram front passenger's vanity mirror light (2 of 2)
AUDIO UNIT
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
CONSOLE ACCESSORY POWER SOCKET
DRIVER'S LUMBAR SUPPORT SWITCH (W/ MEMORY)
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S POWER SEAT ADJUSTMENT SWITCH (W/O MEMORY)
DRIVER'S POWER SEAT CONTROL UNIT (W/ MEMORY)
DRIVER'S SEAT HEATER SWITCH
DRIVER'S SEAT- BACK HEATER
DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
DRIVER'S VANITY MIRROR LIGHT
DVD PLAYER UNIT
ELECTRICAL COMPASS UNIT (W/O NAVIGATION)
FRONT ACCESSORY POWER SOCKET
FRONT INDIVIDUAL MAP LIGHTS
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH (W/ MEMORY)
FRONT PASSENGER'S SEAT BELT SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEATER SWITCH
FRONT PASSENGER'S VANITY MIRROR LIGHT
FRONT PASSENGER'S WEIGHT SENSOR UNIT
GAUGE ASSEMBLY
GLOVE BOX LIGHT
HOME LINK
INTERIOR LIGHTS SWITCH
KEYLESS BUZZER PASSENGER'S MULTIPLEX CONTROL UNIT
KEYLESS RECEIVER UNIT
MOONROOF SWITCH
MULTI- INFORMATION DISPLAY UNIT (W/O NAVIGATION)
NAVIGATION DISPLAY UNIT
NAVIGATION UNIT
OPDS UNIT DRIVER'S SEAT BELT SWITCH
PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PSP SWITCH
RAIN SENSOR, AUTOMATIC WIPER CONTROL UNIT (W/ AUTO WIPER)
REAR BLOWER MOTOR RELAY
REAR BLOWER POWER TRANSISTOR
REAR CONTROLLER, SCREEN (W/ REAR ENTERTAINMENT SYSTEM)
REAR HEATER-A/C CONTROL PANEL UNIT
ROOF CONSOLE
STEREO AMPLIFIER (BOSE)
TRIP METER SELECT/ RESET SWITCH
W/ NAVIGATION
WASHER FLUID LEVEL SWITCH
Go to component -> Ground distribution circuit (2 of 4) -> FRONT PASSENGER'S VANITY MIRROR LIGHT
