Acura Integra IV (2022-2024) windshield wiper control unit/ motor Wiring diagram
This page shows the only wiring diagram for the component.windshield wiper control unit/ motor, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield wiper control unit/ motor (1 of 1)
A/C CONDENSER FAN MOTOR
AUTOMATIC DIMMING INSIDE MIRROR
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BODY CONTROL MODULE
BRAKE FLUID LEVEL SWITCH
CLUTCH PEDAL POSITION SWITCH A
DATA LINK CONNECTOR (DLC)
DC-DC CONVERTER
DC-DC CONVERTER ACC RELAY
DRIVER'S VANITY MIRROR LIGHT
ELECTRIC VACUUM PUMP CONTROL UNIT
FRONT ACCESSORY POWER SOCKET RELAY
FRONT INDIVIDUAL MAP LIGHT
FRONT SEAT HEATER RELAY
HEAD-UP DISPLAY
HEATED STEERING WHEEL RELAY
HOOD LATCH SWITCH
HORN (HIGH)/ SECURITY HORN
HORN (LOW)/ SECURITY HORN
M/T
MOONROOF MOTOR/ CONTROL UNIT
MOONROOF SWITCH
MULTI-PURPOSE CAMERA UNIT
PASSENGER'S VANITY MIRROR LIGHT
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER TRANSISTOR
POWER WINDOW MASTER SWITCH
RELAY CONTROL MODULE
RIGHT FRONT FOG LIGHT
RIGHT HEADLIGHT
TAILGATE RELEASE ACTUATOR RELAY
UNDER-HOOD FUSE/RELAY BOX
VSA OFF SWITCH
WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER MOTOR
WINDSHIELD WIPER CONTROL UNIT/ MOTOR
Go to component -> Ground distribution circuit (4 of 4) -> WINDSHIELD WIPER CONTROL UNIT/ MOTOR
