Acura Integra IV (2022-2024) thermal joint 8 Wiring diagram
This page shows the only wiring diagram for the component.thermal joint 8, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram thermal joint 8 (1 of 1)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BLU WIRE
CLIMATE CONTROL UNIT
DATA LINK CONNECTOR (DLC)
DRIVER'S POWER SEAT CONTROL UNIT
FRONT SEAT HEATER CONTROL UNIT
FUSE 19
HEAD-UP DISPLAY
HOT AT ALL TIMES
JUNCTION BOX A
JUNCTION BOX D (LEFT SIDE OF DASH)
LEFT HEADLIGHT
LEFT SIDE BSI RADAR UNIT
LT BLU WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RELAY CONTROL MODULE
RIGHT HEADLIGHT
RIGHT SIDE BSI RADAR UNIT
TAN WIRE
THERMAL JOINT 7
THERMAL JOINT 8
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
WIRELESS CHARGER
YEL WIRE
Go to component -> Computer data lines circuit (1 of 5) -> THERMAL JOINT 8
