Acura Integra IV (2022-2024) stereo amplifier Wiring diagrams
This page contains all the electrical diagrams for the component. stereo amplifier, in which he is found in the car Acura Integra IV (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram stereo amplifier (1 of 2)
BASE
BLK WIRE
CENTER, RIGHT REAR SEAT BELT BUCKLE SWITCH
CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE
CVT DRIVE PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT DRIVEN PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT LOCK-UP CLUTCH CONTROL SOLENOID VALVE
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S POWER SEAT CONTROL UNIT
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT POSITION SENSOR
ELECTRIC OIL PUMP
EPS MOTOR/ CONTROL UNIT
EXCEPT BASE
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FTP SENSOR SHIELD
FUEL TANK UNIT
GRN WIRE
GRY WIRE
LEFT REAR DOOR LATCH
LEFT REAR DOOR OUTER HANDLE LIGHT
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SEAT BELT BUCKLE SWITCH
LEFT REAR SEAT HEATER
POWER LUMBER SUPPORT SWITCH
RED WIRE
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR OUTER HANDLE LIGHT
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT HEATER
STEREO AMPLIFIER
TCM
TRANSMISSION RANGE SWITCH
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (1 of 4) -> STEREO AMPLIFIER
Wiring diagram stereo amplifier (2 of 2)
ADAPTIVE DAMPER CONTROL UNIT
AUDIO REMOTE- HFL SWITCH
BLU WIRE
CABLE REEL
CAN GATEWAY
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
ELECTRIC PARKING BRAKE/ AUTOMATIC BRAKE HOLD SWITCH
EPS CONTROL UNIT
FROM FUSE 9 (DIAGRAM 5 OF 6)
FROM UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 6)
FROM UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 6)
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT SEAT HEATER RELAY
FUSE 1
FUSE 10
FUSE 16
FUSE 2
FUSE 22
FUSE 25
FUSE 26
FUSE 28
FUSE 40
FUSE 41
FUSE 48
FUSE 49
FUSE 53
FUSE 54
FUSE 55
FUSE 56
GRN WIRE
JUNCTION BOX G
LT BLU WIRE
LT GRN WIRE
MOONROOF MOTOR/ CONTROL UNIT
OPTION CONNECTOR (DRIVER'S DOOR)
OPTION CONNECTOR (PASSENGER'S DOOR)
PNK WIRE
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PPL
RED WIRE
SRS UNIT
STEREO AMPLIFIER
TAILGATE RELEASE ACTUATOR RELAY
TO JUNCTION BOX G (DIAGRAM 5 OF 6)
VSA MODULATOR CONTROL UNIT
W/ AMPLIFIER
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 6) -> STEREO AMPLIFIER
