Acura Integra IV (2022-2024) roof antenna Wiring diagrams

This page contains all the electrical diagrams for the component. roof antenna, in which he is found in the car Acura Integra IV (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

roof antenna wiring diagram (1 of 4)

2-WAY TRANSCEIVER B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ENGINE START/STOP SWITCH FUSE 19 FUSE 4-5 FUSE 5-7 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOOD LATCH SWITCH HOT AT ALL TIMES IMMOBILIZER/ SECURITY INDICATOR JUNCTION BOX D LF ANTENNA LOCK SWITCH LT BLU WIRE LT GRN WIRE NCA WIRE OUTER HANDLE SWITCH PNK WIRE PPL RED WIRE RELAY CONTROL MODULE ROOF ANTENNA TAILGATE OUTER HANDLE/ LOCK SWITCH TAN WIRE UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Anti-theft circuit (3 of 5) -> ROOF ANTENNA

roof antenna wiring diagram (2 of 4)

AUDIO UNIT B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DC-DC CONVERTER ACC RELAY FUSE 36 FUSE CC FUSE/RELAY HOLDER A GAUGE CONTROL MODULE GNSS ANTENNA GRY WIRE HOT AT ALL TIMES LEFT REAR DOOR SPEAKER LEFT REAR DOOR TWEETER LIN TRANSCEIVER LT BLU WIRE LT GRN WIRE NCA WIRE PCM PNK WIRE PPL RED WIRE RIGHT REAR DOOR SPEAKER RIGHT REAR DOOR TWEETER ROOF ANTENNA UNDER- HOOD FUSE/ RELAY BOX WHT WIRE YEL WIRE

Go to component -> Navigation circuit, w/o amplifier (1 of 3) -> ROOF ANTENNA
