Acura Integra IV (2022-2024) rear window defogger/ mirror defogger switch indicator Wiring diagram
This page shows the only wiring diagram for the component.rear window defogger/ mirror defogger switch indicator, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window defogger/ mirror defogger switch indicator (1 of 1)
BLK WIRE
BRN WIRE
CLIMATE CONTROL SWITCH
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DOOR MULTIPLEX CONTROL UNIT
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 1
FUSE 2
FUSE 3-4
FUSE 43
GRN WIRE
HOT AT ALL TIMES
JUNCTION BOX A
LEFT POWER MIRROR
LT BLU WIRE
MIRROR DEFOGGER
PNK WIRE
POWER WINDOW MASTER SWITCH
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER/ MIRROR DEFOGGER SWITCH
REAR WINDOW DEFOGGER/ MIRROR DEFOGGER SWITCH INDICATOR
RED WIRE
RELAY ENERGIZED
RIGHT POWER MIRROR
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
Go to component -> Defoggers circuit -> REAR WINDOW DEFOGGER/ MIRROR DEFOGGER SWITCH INDICATOR
