Acura Integra IV (2022-2024) position/ daytime running light indicator Wiring diagram
This page shows the only wiring diagram for the component.position/ daytime running light indicator, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram position/ daytime running light indicator (1 of 1)
0) LOW 1) HIGH 2) PASS
0) OFF 1) ON
0) OFF 1) PARK 2) AUTO 3) HEAD
AUTO HIGH BEAM INDICATOR
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
DIMMER/ FLASH-TO- PASS SWITCH
FRONT FOG LIGHT INDICATOR
FRONT FOG LIGHT RELAY
FRONT FOG LIGHT SWITCH
FUSE 15
FUSE CD
FUSE/RELAY HOLDER A
GAUGE CONTROL MODULE
GRY WIRE
HEADLIGHT SWITCH
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT W/ DC-DC
JUNCTION BOX D
LEFT FRONT FOG LIGHT
LIGHTS ON INDICATOR
LT BLU WIRE
MULTI-INFORMATION DISPLAY (MID)
PNK WIRE
POSITION/ DAYTIME RUNNING LIGHT INDICATOR
PPL
RED WIRE
RELAY CIRCUIT BOARD
RELAY CONTROL MODULE
RELAY ENERGIZED
RIGHT FRONT FOG LIGHT
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit (1 of 2) -> POSITION/ DAYTIME RUNNING LIGHT INDICATOR
