Acura Integra IV (2022-2024) neutral position sensor Wiring diagram
This page shows the only wiring diagram for the component.neutral position sensor, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram neutral position sensor (1 of 1)
A/F SENSOR (SENSOR 1) (EXHAUST MANIFOLD)
BLK WIRE
BLU WIRE
BRN WIRE
CMP SENSOR A
CVT
ECT SENSOR 2
EVAP CANISTER PURGE VALVE
GRN WIRE
GRY WIRE
INPUT SHAFT (MAINSHAFT) SPEED SENSOR
LT BLU WIRE
LT GRN WIRE
M/T
NEUTRAL POSITION SENSOR
PCM
PNK WIRE
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRY WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/TAN WIRE
PPL/WHT WIRE
PPL/YEL WIRE
RED WIRE
ROCKER ARM OIL CONTROL SOLENOID
ROCKER ARM OIL PRESSURE SENSOR
TAN WIRE
THERMAL JOINT 1
THERMAL JOINT 2
TRANSMISSIONS SYSTEM
TURBOCHARGER BYPASS CONTROL SOLENOID VALVE
VTC OIL CONTROL SOLENOID VALVE A
VTC OIL CONTROL SOLENOID VALVE B
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo (8 of 8) -> NEUTRAL POSITION SENSOR
