Acura Integra IV (2022-2024) individual/ dynamic mode/ idle stop off switch Wiring diagram
This page shows the only wiring diagram for the component.individual/ dynamic mode/ idle stop off switch, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram individual/ dynamic mode/ idle stop off switch (1 of 1)
ACC COMBINATION SWITCH
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL SWITCH
ELECTRIC PARKING BRAKE/AUTOMATIC BRAKE HOLD SWITCH
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUSE 54
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HEATED STEERING WHEEL SWITCH
HOT AT ALL TIMES
INDIVIDUAL/ DYNAMIC MODE/ IDLE STOP OFF SWITCH
LEFT REAR SEAT HEATER SWITCH
LT BLU WIRE
LT GRN WIRE
MOONROOF SWITCH
REAR SEAT HEATER CONTROL UNIT
REAR USB CHARGER UNIT
RED WIRE
RIGHT REAR SEAT HEATER SWITCH
SHIFT POSITION INDICATOR
SRS UNIT
THERMAL JOINT 5
THERMAL JOINT 6
UNDER-DASH FUSE/RELAY BOX
USB PORT HOLDER
VSA OFF SWITCH
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> INDIVIDUAL/ DYNAMIC MODE/ IDLE STOP OFF SWITCH
