Acura Integra IV (2022-2024) grn Wiring diagram
This page shows the only wiring diagram for the component.grn, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram grn (101 of 101)
BLK WIRE
BRN WIRE
ENGINE OIL PRESSURE SENSOR
GRN WIRE
GRY WIRE
ICM
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
LT BLU WIRE
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/LT BLU WIRE
PPL/PNK WIRE
PPL/TAN WIRE
PPL/WHT WIRE
RED WIRE
SPARK PLUG
TAN WIRE
THERMAL JOINT 3
THERMAL JOINT 4
TURBOCHARGER (LEFT SIDE OF ENGINE)
TURBOCHARGER BOOST SENSOR
TURBOCHARGER WASTEGATE CONTROL ACTUATOR
TURBOCHARGER WASTEGATE CONTROL ACTUATOR POSITION SENSOR
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo (6 of 8) -> GRN WIRE
