Acura Integra IV (2022-2024) front up-down switch Wiring diagram
This page shows the only wiring diagram for the component.front up-down switch, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front up-down switch (1 of 1)
BACKWARD
BLK WIRE
BRN WIRE
DOWN
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S POWER SEAT HEIGHT MOTOR
DRIVER'S POWER SEAT RECLINE MOTOR
DRIVER'S POWER SEAT SLIDE MOTOR
DRIVER'S POWER SEAT TILT MOTOR
FORWARD/
FRONT UP-DOWN SWITCH
FUSE 40
FUSE 41
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
REAR UP-DOWN SWITCH
RECLINE SWITCH
RED WIRE
SLIDE SWITCH
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> FRONT UP-DOWN SWITCH
