Acura Integra IV (2022-2024) front turn signal light Wiring diagram
This page shows the only wiring diagram for the component.front turn signal light, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front turn signal light (1 of 1)
AUTO
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
DIMMER
FRONT TURN SIGNAL LIGHT
FUSE 27
FUSE 30
FUSE 44
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HEAD
HOT AT ALL TIMES
JUNCTION BOX E
JUNCTION BOX G
LEFT HEADLIGHT
LIGHTING CONTROL UNIT
LT BLU WIRE
OFF
PARK
PASSING
PNK WIRE
POSITION/ DAYTIME RUNNING LIGHT
PPL
REAR TURN SIGNAL LIGHT
RED WIRE
RELAY ENERGIZED
RIGHT HEADLIGHT
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 3) -> FRONT TURN SIGNAL LIGHT
