Acura Integra IV (2022-2024) front passenger's power seat recline motor Wiring diagram
This page shows the only wiring diagram for the component.front passenger's power seat recline motor, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's power seat recline motor (1 of 1)
BACKWARD
BLK WIRE
BLU WIRE
FORWARD/
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER SEAT RECLINE MOTOR
FRONT PASSENGER'S POWER SEAT SLIDE MOTOR
FUSE 49
FUSE 53
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
PNK WIRE
PPL
RECLINE SWITCH
RED WIRE
SLIDE SWITCH
UNDER-DASH FUSE/RELAY BOX
YEL WIRE
Go to component -> Passenger power seat circuit -> FRONT PASSENGER'S POWER SEAT RECLINE MOTOR
