Acura Integra IV (2022-2024) front passenger's knee air bag inflator Wiring diagram
This page shows the only wiring diagram for the component.front passenger's knee air bag inflator, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's knee air bag inflator (1 of 1)
BLU WIRE
BRN WIRE
DRIVER'S KNEE AIR BAG INFLATOR
FRONT PASSENGER'S KNEE AIR BAG INFLATOR
GRN WIRE
GRY WIRE
LEFT "C" PILLAR)
LEFT FRONT IMPACT SENSOR
LEFT SIDE IMPACT SENSOR (FIRST)
LEFT SIDE IMPACT SENSOR (SECOND)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT FRONT IMPACT SENSOR
RIGHT SIDE IMPACT SENSOR (FIRST)
RIGHT SIDE IMPACT SENSOR (SECOND)
SRS UNIT
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 4) -> FRONT PASSENGER'S KNEE AIR BAG INFLATOR
